CD/USB/SD/MP3 Slot in Player with RS232

• Buyers of all AMC products can purchase finished products or modules CKD. The more each purchase or cumulative purchase (including global market group purchases or link-introduced purchases), the more favorable the price (up to dealer or distributor prices), and can be specially made. Or do their own printing/branding.
• * All AMC customers can join AMC as a member and use the services of AMC members, including making reservations to use the AMC showroom in Zhonghe, Taiwan, for seminars or activities with AMC staff.
•
  * * Marketed in the global market. Received excellent Reviews in Europe and the United States. AMC IoT IA Innovations 2002 CES-Design & Engineering Showcase Award Series
• * Super-precision automotive shockproof industrial level automatic slot-in CD turntable, which can achieve excellent sound quality for playing CD, MP3.
• * Designed to play standard uncompressed PCM discs (hereinafter referred to as "CD"), MP3 compressed discs (hereinafter referred to as "MP3"), USB, SD.
• * Through RS232, XCDise digital and analog can be connected to the AMC IoT IA system. *Burr Brown's 24-bit/192 KHz sampling advanced segmented D/A converter architecture using TI's PCM1798 enables excellent dynamic performance (typically 123dB) and increased tolerance to clock jitter. This DAC offers excellent SNR up to 123dB (typ), excellent THD+N as low as 0.0005% (typ), and an excellent 8x oversampled digital filter that reduces passband ripple to +- 0.002dB. The DAC can handle sampling frequencies from 10KHZ to 200kHz, accepts 16-bit, 20-bit and 24-bit audio data, and is equipped with digital enhancement functions. * Unique 5-pole linear active LPF (low-pass filter) prevents interference from ultrasonic noise common in other CD playback systems.
• * 100~240VAC switching power supply suitable for global markets, with independent windings for digital, analog and servo to achieve excellent sound quality. Create a green design with ultra-low carbon footprint through durable module design. * XCDise can be upgraded to XCDise-vt, which delivers the ultra-soft vacuum tube sound. *Dimensions (width x height x depth): 430×82×288 mm
•  * Such as TSMC/NVIDIA (Huida) globalization, global combination: Design in USA, UK / ID in Germany / Made in Taiwan * AMC SINCE 1970 - JIT (Just In Time: Just in time) SOD (Service on Demand: Tailor-made - can produce customized project production and provide services according to customer needs) Partnership (Partner - can make necessary combinations with other products according to customers)
   * Please refer to AMC
  *
   * Size / Color Variants: Standard size (width x height x depth): 430×82×288 mm
   *Customized size: size required by customer
•
   *Color: Standard Color: Black Customized Color: Customer's requested color
•
   * Number of packages Pack Size: Standard packaging: each unit is packed into the inner carton Gift Box. Every four inner cartons Gift Boxes are packed into one outer carton Shipping Carton. Customized packaging: according to customer requirements
•
   * Certification obtained by the factory: ETC ISO9001 certification. Verification certificate number: 3E2Y019-03
•
  * Can play PCM CD, MP3 CD, USB and SD card
•
  * Use Burr BrownPCM1798 (24Bit/192KHz) decoding chip to achieve good dynamic performance
•
  * RS232 interface
•
  * EIA calibrated audio output ensures matching between preamplifier and receiver
•
  * Full-featured infrared remote control song selection function
•
  * Vacuum tube 12AU7*2
•
  * Disc capacity single disc: 120 or 80mm Digital filter: 8 times oversampling rate, sampling rate up to 24Bit/192KHz Analog filter: 5-pole effective frequency response (5Hz-20KHz): <+ l-0.2dBDe-Emphasis error: <+l-0.2dB Linearity: +/-0.5 dB; 0-100dB channel spacing (20Hz to 20KHz): >100 dB Channel imbalance: <+/- 0.1 dB Signal-to-noise ratio (A-weighted): 115 dB Dynamic Range: >102dB Total Harmonic Distortion (0dB, 1 KHz.A weighted): 0.0011% Intermodulation Distortion (19 & 20 Khz): <-110dB Output Impedance: 120 Ohm Digital Error Correction: CIRC with dual in C1 & C2 Error correction ◆ S/PDIF digital output Digital output level: 0.5 Vpp Peak emission wavelength: 660 nm Load impedance: 75 ohm Dimensions, J x H x D): 430x82x300 mm Net weight: 4.0 kg
•
  * Custom-made (SoD - Service on Demand): a. Produce and provide products according to user needs, including product color and printing. b. Provide various modules and parts

• AMC 所有產品 購買者皆可以購買成品or模組 CKD, 每次購買或累積購買愈多 (包括 全球市場 團購或联结介绍的購買), 價格愈優惠 (up to dealer or distributor prices) , 並可特製或做各自印刷/品牌.
• AMC 客户皆可加入 AMC 為會員 使用AMC會員的服務 包括预约使用 AMC 台灣 中和的展示室與AMC人員研討或活動.
• * 行銷全球市場.欧美都收到絕佳Reviews. AMC IoT IA Innovations 2002 CES-Design & Engineering Showcase Award 系列
  * 超精度車用防震工業彼級自動吸入式CD轉盤，可實現出色的音質播放CD、MP3。
  * 設計用於播放標準無壓縮PCM光碟（以下我們稱為"CD"）、MP3 壓縮光碟（以下我們稱為"MP3"）、USB、SD。
  * 透過 RS232,XCDise 的數位和類比可以與 AMC IoT IA 系統連接。
  *使用 TI PCM1798 的 Burr Brown 24位元/192 KHz 取樣進階分段D/A 轉換器架構可實現出色的動態效能（通常為123dB）並提高對時脈抖動的容限。這款DAC 提供高達123dB（典型值）的出色SNR、低至 0.0005%（典型值）的出色 THD+N， 以及出色的8x 過採樣數位濾波器，使通帶紋波降至 +- 0.002dB。DAC 可以處理 10KHZ 至 200kHz的取樣頻率，接受16位元、20位元和 24 位元音訊數據，並安裝了數位去加強功能。
  * 獨特的5極線性主動 LPF（低通濾波器）可防止其他 CD 播放系統中常見的超音波雜訊的干擾。
  * 適用於全球市場的100~240VAC 開關電源，具有數位、類比和伺服各自獨立繞組，可實現卓越的音質。透過持久的模組設計，打造超低碳足跡的綠色設計。
  * XCDise 可以升級為 XCDise-vt，具有超凡柔和的真空管聲音。
  *尺寸（寬x高x深）：430×82×288毫米
  * 如台積電/NVIDIA（輝達）全球化，全球組合：Design in USA,UK / ID in Germany / Made in Taiwan
  * AMC SINCE 1970 -
        JIT （Just In Time：剛好即時）
        SOD （Service on Demand： 量身訂做-- 可依客户需求量生訂做 專案生產提供 服務）
        Partnership（合作伙伴—- 可依客户與其它產品 做必要的搭配）
• 請叁考 AMC
• • 尺寸 / 顏色 Size / Colour Variants：
    標準 尺寸 （寬x高x深）：430×82×288毫米
  • 客製化尺寸：客户要求尺寸
  • 顏色：
    標準顏色：黑色
    客製化顏色：客户要求顏色
  • 包裝入數 Pack Size：
    標準包裝：每一台裝入內紙箱Gift Box. 每四個內紙箱Gift Boxes 裝入一個 外紙箱Shipping Carton.  客製化包裝：依客户要求
  • 工廠所具備之認證 Certification obtained：ETC ISO9001 認證. 驗證證書編号：3E2Y019-03
• 可播放PCM CD、MP3 CD、USB及SD卡
• 使用Burr BrownPCM1798(24Bit/192KHz)解碼晶片達到良好的動態表現
• RS232介面
• EIA校準音頻輸出確保前置擴大機和接受器的匹配
• 全功能紅外線遙控器選曲功能
• 真空管12AU7*2
• 碟片容量單碟：120或80mm
  數字濾波器：8倍過採樣率，採樣率高達24Bit / 192KHz
  模擬濾波器：5極有效頻率響應（5Hz-20KHz）： <+ l-0.2dB
  De-Emphasis error： <+ l-0.2dB
  線性度： + /-0.5 dB; 0-100dB
  通道間隔（20Hz至20KHz）： > 100 dB
  通道不平衡： <+/- 0.1 dB
  信噪比（A加權）： 115 dB
  動態範圍： > 102dB
  總諧波失真（0dB，1 KHz.A加權）： 0.0011％
  互調失真（19＆20 Khz）： <-110dB
  輸出阻抗： 120歐姆
  數字錯誤校正： CIRC在C1和C2中具有雙重錯誤校正

  ◆ S/PDIF數字輸出
  數字輸出電平： 0.5 Vpp
  峰值發射波長： 660 nm
  負載阻抗： 75歐姆
  尺寸ry，J xH x D）： 430x82x300毫米
  淨重： 4.0公斤
• 量身訂作 (SoD - Service on Demand) : a. 依使用者需求包括產品顏色及印刷 生產提供產品. b. 提供 各模組 及零件
